CApture BT Fuming Chamber - Standard

This benchtop chamber with microprocessor control automates the Cyanoacrylate (CA) fuming of evidence. The programmable operating system combines the control and monitoring of all critical parameters in the Super Glue fuming process with the precision to store and easily repeat specified programs. Its spacious interior with shelving system maximizes fuming capacity and accommodates large evidence including long guns.

PRODUCT SPECIFICATIONS:

• Type 304 brushed stainless steel interior with removable perforated floor, four stainless steel hanging rods (26.9" long x 3/8" dia.) and quick-release sidewall brackets mounted at four heights.
• Powder-coated steel exterior
• Interior space of 19 cubic feet and 58.6" diagonal dimension
• Built-in humidifier and compartment with 500 ml water bottle
• Built-in CA fuming compartment with heater plate
• Tempered safety glass door with electronic door lock to prevent opening during the fuming cycle. Includes power outage override.
• Interior LED light for illumination and 30-minute end-of-fuming-cycle alert
• ECM recirculation blower
• Exhaust blower
• Full-color, eye-level LCD control screen for display of programs, program parameters, number of completed fuming cycles, filter life remaining, low level water reservoir and open door alerts
• Microprocessor-controlled operating system for adjustment of chamber humidity to 80% +/- 5% relative humidity, pre-fuming humidity incubation, fuming temperature up to 424° F within +/- 1%, and fuming and exhaust times. Stores 20 programs. Includes 3 factory set programs: Low Heat, High Heat, Lumincyano. Includes diagnostic mode with audible/visual alerts for program cycle completion.
• Acti-Vent Smart Controls with programmable purge time, standby exhaust mode and cleaning mode
• Drawer, 28" w x 13" d x 1.5" h (71 x 33 x 4 cm) with flush-mounted disappearing handle and 5" x 6" platform
• One each Prefilter, Carbon Filter and Humidifier Filter are included and accessible from inside the chamber
• Four leveling feet, 10' (3 meter) power cord and plug
• Super Glue, fuming dishes, and purified water are required (not included)
• Shipping weight 350 lbs. (159 kg)
